DRIVETRAIN-TA65 Star
54
2. SHIFTER SHAFT SUB ASSEMBLY:
Gently hammer the double dowel pins of the shifter
fork after placing in vice to remove the shifter fork
from shifter shaft as marked in
3. SHIFTER FORKS:
1. 5th gear shifter fork is longer than 3, 4
th
gear
shifter forkend has dowel hole in the center of
the boss.
2. 3rd and 4th gear fork has shorter ribs.
3. 1st and 2nd gear shifter fork has the smaller
two ribs with shifter finger integrated to fork
itself.
