10.Install the spacer over output shaft splines in

the cover assembly.

11.Press the new oil seal into the cover assembly.

G. REAR OUTPUT YOKE

1. Press new dust deflector on the yoke.

(If

removed)

2. Position the yoke assembly on the upper output

shaft in transfer case and install the end yoke

assembly

(1),

seal

(2),

washer

(3)

and nut

(4).

3. Holding the end yoke, tighten the nut.
