ENGINE
28
Intake System Components :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Gasket (Intake Manifold)
02
Intake Manifold
03
Gasket, Intake Manifold To Intake Adapter
04
Gasket
05
Gasket (Intake Adaptor)
06
Hex FL Screw M6X30 (Qty – 3)
1
+0.2
07
Assembly Adaptor – Flange
08
Intake Adaptor
09
Hex FL Nut AM8 (Qty – 9)
2.2
+0.3
10
EGR Cooler
11
Hex FL Bolt M8X28 (Qty – 1)
2
+0.3
12
Hex FL Bolt M6X70 (Qty – 2)
1
+0.2
13
Hex FL Screw M6X12
1
+0.2
14
Hex FL Screw M5X12
1
+0.2
15
Assembly. EGR Pipe (Outlet)
16
Hex FL Screw M6X20 (Qty – 4)
1
+0.2
17
Hex FL Screw M6X20 (Qty – 2)
1
+0.2
18
Assembly EGR Inlet Pipe
19
Gasket
20
Flanged Clinch Nut M6 (Qty – 2)
1
+0.2
