60 / 1906
ENGINE
24
Special Installation :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Assembly Power Steering Pump
02
Hex FL Screw M8X25 (Qty – 1)
3
+0.3
03
Bracket (Power Steering Pump)
04
Hex FL Bolt M8X85 (Qty – 2)
3
+0.3
05
Hex FL Screw M8X25 (Qty -4)
2.2
+0.3
06
Pulley
07
Spring Washer (Qty – 3)
08
Hex Screw M8X16 (Qty – 3)
2.5
09
Belt
10
Assembly Vibration Damper
11
AC Belt
12
Tensioning Screw AC Compressor
13
Roller (AC Belt Tensioner)
14
Collar Screw M10X30 (Qty – 1)
3
+0.3
15
Hex FL Bolt M10X130 (Qty – 1)
3
+0.3
16
Hex FL Screw M10X45 (Qty – 1)
3
+0.3
17
Bracket for EMS Harness Clamping
18
Compressor
19
Hex FL Bolt M8X75 (Qty – 3)
3
+0.3
20
Alternator
21
Bracket (Alternator Cable Mounting )
22
Hex FL Screw M6X14 (Qty – 1)
23
Nyloc Nut M10
24
Bright Washer
25
Hex FL Bolt M8X35 (Qty – 4)
3
+0.3
26
Bracket (Alternator, AC Compressor Bkt)
