62 / 1906
ENGINE
26
Exhaust System Components :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Gasket (Air Intake Scoop to Turbocharger)
02
Assembly Pipe (TC Air Inlet)
03
Hex FL Nut AM6 (Qty – 3)
1
+0.2
04
Gasket (Exhaust Manifold)
05
Exhaust Manifold
06
Stiffner Assembly (Exhaust Manifold)
07
Hex FL Bolt M8X28 (Qty – 1)
08
Heat Shield Rear (Exhaust Manifold)
09
Hex FL Screw M6X10 (Qty – 3)
1
+0.2
10
Flanged Clinch Nut (Qty – 9)
2
+0.3
11
Heat Shield Front (Exhaust Manifold)
12
Hex FL Screw M6X10 (Qty – 2)
1
+0.2
13
Flanged Clinch Nut (Qty – 3)
3
+0.3
14
Turbocharger Assembly
15
Assembly Turbocharger Heat Shield
16
Hex FL Screw M6X10 (Qty – 2)
1
+0.2
