ENGINE
18
Engine :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Bracket (Oil Mist Separator Mounting)
02
Hex FL Screw M6X16 (Qty – 2)
1
-0.2
03
Rear Side (Timing Cover)
04
Hex FL Screw M6X16 (Qty – 4)
1
-0.2
05
Front Cover (Timing Belt)
06
Hex FL Bolt M6X25 (Qty – 7)
1
-0.2
07
Bottom Side (Timing Cover)
08
Hex FL Screw M6X16 (Qty – 2)
1
-0.2
09
Bolt (Main Bearing M12X1.5)
10
Main Bearing Cap
11
Assembly Dipstick Tube
12
Hex FL Screw M6X14 (Qty – 1)
