Cylinder Head and Cover :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Injector
02
Hex FL Bolt M8X40 (Qty – 4)
3
+0.3
03
Injector Claw
04
Hex FL Screw M6X10 (Qty – 2)
05
Support Bracket 2 Hose ( OMS to TC Inlet)
06
Cylinder Head Cover Gasket
07
Bearing Frame
08
Hex Bolt (Cylinder Head) (Qty – 10)
Step 1-
6±0.5
Torque
Step 2-
90
0
±5
0
angle
Step 3-
90
0
±5
0
angle
09
Glow Plug
10
Hex FL Screw M6X25 (Qty – 3)
1
+0.2
11
Vacuum Pump
12
Vacuum Pump Gasket
13
Coolant Adaptor (On Cylinder Block)
14
Hex FL Bolt M6X20 (Qty – 1)
1
+0.2
15
Hex FL Bolt M6X60 (Qty – 1)
1
+0.2
16
Gasket (Coolant Adaptor to Block)
17
Gasket (Cylinder Head)
18
Cylinder Head Assembly
19
Washer (For Cylinder Head Bolt)
20
Cam Sensor
21
Hex FL Screw M6X16 (Qty – 1)
22
Hex FL Bolt M6X40 (Qty – 26)
1.2
23
Cylinder Head Cover
24
Oil Filler Cap
25
Hex FL Bolt M6X40 (Qty – 13)
1
-0.2
26
Spherical Washer
