ENGINE
20
Oil Sump :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Cylinder Crankcase
02
Ladder Frame
03
Hex FL Bolt M6X25 (Qty – 24)
1
+0.2
04
Oil Sump Gasket
05
Oil Sump
06
Hex FL Screw M6X18 (Qty – 12)
1
+0.2
07
Hex FL Screw M6X30 (Qty – 8)
1
+0.2
08
Hex FL Screw (Qty – 4)
09
Drain Plug
10
Sealing Washer (Oil Sump Drain Plug)
11
12
Gasket (Rear Cover Crankcase)
13
Rear Cover Crankcase
14
15
Hex FL Screw M6X20 (Qty – 6)
1
+0.2
