ENGINE
190
3
Sensor ( - )
4
Motor ( - )
5
Motor ( + )
CAUTION:
Intake Throttle Sensor
Reset
need to be acti-
vated in Diagnostic Tool whenever intake
throttle is changed.
19. GUIDELINES FOR PERFORMING IN SERVICE FUNCTIONAL RESET FOR VARIOUS SENSORS:
EMS performs learning of below mentioned sensors and actuators at regular intervals to ensure efficient func-
tionality. In case of replacement of these sensors or if any activity is conducted as indicated in the table below,
sensor learning needs to be reset. Procedure as indicated in diagnostic tool explains the process to be followed
