HEXA

HVAC

K. CONDENSER

1. Remove the radiator,

(refer Radiator removal

process.)

2. Loosen and remove the 4 condenser mounting

bolts on the radiator and separate out the con-

denser.

CAUTION

Never leave the condenser lines open immediately

cover them with caps, otherwise the desiccant which

is in-built in the condenser may absorb the moisture

from surrounding air and get contaminated.
