MOUNTING AT LOCATION “A”
MOUNTING AT LOCATION “B”
MOUNTING AT LOCATION “C AND D”
MOUNTING AT LOCATION “E”
SR
NO.
DESCRIPTION
1
Special hex bolt M12x220
2
Washer
3
Rubber mounting top
(At location A & E)
4
Tube body mount
5
Rubber mounting bottom
(At location A & E)
6
Washer
7
Nyloc nut M12
8
Bright washer 13
9
Spring washer B12
10 Special hex bolt M12x120
11 Rubber mounting top
(At location C & D)
12 Tube body mount
13 Rubber mounting bottom
(At location C
and D)
14 Washer
15 Rubber mounting top
(At location B)
16 Tube body mount
17 Rubber mounting bottom
(At location B)
18 Special hex bolt M12x150
19 Tube body mount
