TAILGATE DIMENSIONS:
A, B, C & D are the Centre points of the hinges and the tailgate striker. All measurements need to be
measured with respect to these centers.
Dimensions in Rear View:
SR. NO.
MEASUREMENT POSITION
LENGTH (mm)
1
A-D
1072
2
B-C
1072
