STEERING
28
7.2.3.2 SYSTEM LAYOUT
SR.
NO.
DESCRIPTION
01 Assembly Top Column
02 Thin Castle Nut M12X1.5
03 Split Pin 3.2X25
04 Spring Washer B12
05 Hex Bolt M12X1.5X65
06 Washer Eyebolt Dia 35XDia 13XThk 3
07 Rack and Pinion
08 Hex FL Nut AM12X1.5
09 Bellow Plate
10 Assembly Rubber Bellow
11 Hex FL Screw M6X12
12 Hex Screw M8X30
13 Spring Washer B8
14 Washer
