STEERING
24
STEERING WHEEL
REMOVAL
1. Pull out the horn pad assembly.
!!WARNING
In case of Airbag versions refer DAB removal pro-
cedure in SRS section
.
2. Disconnect the horn pad connection and sepa-
rate the horn pad assembly.
3. Loosen and remove the steering wheel lock nut
and take out the steering wheel (Steering wheel
puller 2779 5890 46 01)
FITMENT
For fitment follow the reverse procedure of removal
1.2.3 ON VEHICLE REPAIRS
1.2.3.1 STEERING WHEEL REMOVAL
(With DAB)
1. Park the car with front wheel in straight ahead
position. Apply parking brake and place wheel
chokes at rear wheels.
2. Disconnect battery and wait for 2 minutes.
3. Insert & Push the screw driver from bottom cov-
er to disengage DAB snap at 6'o clock side of
steering wheel.
4. Rotate steering wheel in 90 degree clockwise
direction, insert and push screw driver from bot-
tom cover to disengage DAB snap.
