FRONT AXLE (4X4)
15
FRONT AXLE
(4X4)
8. Disconnect steering rack and pinion OBJ end
from stub axle. (
For removal procedure refer
Steering section
)
9. Remove front wheel speed
sensor (For procedure
refer ABS section)
and remove the bracket from
the knuckle.
10.Loosen and remove the mounting nut of ARB
(Anti roll bar)
link assembly from stub axle.
! CAUTION
Allen key has to be used to hold the ARB link while
loosening or tightening to avoid damage to the link
(For procedure refer ARB removal in Front suspen-
sion section)
11.Remove the drive shaft nut which was loosen
earlier.
