GEAR BOX 6450
20
3.2
GEAR BOX DISMANTLING ON BENCH
PROCEDURE:
(For 4X2 and 4X4 vehicles)
1. Disconnect electrical connections.
A.
For 4X4
vehicle remove the extension bracket
and transfer case before on bench procedure.
2. Remove the magnetic drain plug and drain the
gearbox oil.
3. Remove the clutch release bearing and clutch
release fork. (Refer clutch removal procedure.)
4. Loosen and remove clutch-housing hexagonal
nuts and separate the clutch housing from the
gearbox.
5. Loosen and remove the mounting bolt of
gearbox tubular bracket.
6. Loosen and remove both extension arm end
pin and table spiral pin.
