GEAR BOX 6450
26
NOTE:
Carefully place / reinstall the Spacer while
assembling Gearbox.
33. Remove the spiral pin from the Shifter dog
and remove the shifter dog of Reverse gear.
NOTE:
Proper support need to be provided to shifter dog
while removing the spiral pins. Discard the spiral
pins once used.
CAUTION:
Place the lock hex nut for avoiding the front
housing slippage from the gearbox.
34. Flip the gearbox mounting assembly such that
drive shaft end face is in upward direction.
35. Loosen and remove the gear case front cover
assembly along with the oil seal and remove
the cover gasket.
NOTE:
Ensure the Double Locking is done (engaging the
both 4
th
and 2
nd
gear) before starting the removal
of counter shaft bolt.
