HVAC
73
DISMANTLING
1. Remove mounting bracket from AC assembly
from both ends.
2. Loosen and remove 4 mounting screws from top
side & 2 from bottom side of AC of bezel and take
out the bezel (
Follow same procedure for both
bezels
).
INSPECTION
Refer the inspection points of AC system given for
front HVAC assembly.
ASSEMBLY
For assembly follow the reverse procedure of re-
moval.
