BODY
46
9.2.18DOOR LATCH REAR
REMOVAL
SR.
NO
DESCRIPTION
1
Inner handle (Rear Door)
2
Cable inner handle to latch
3
Cable pop knob to latch
4
Link outer handle to latch
5
Latch
6
Outer door handle
1. Remove the door trim
(For procedure refer
door trim removal procedure in this section.)
2. Remove inner handle (refer inner handle
removal procedure in this section).
3. Disconnect electrical connector.
4. Disconnect the cables of inner door handle and
take out the same.
5. Disconnect the link between outer door lock and
latch at door handle end.
6 Loosen three mounting screws and take out the
latch.
FITMENT
For fitment follow reverse procedure of removal
