1095 / 1236
BODY
35
BODY
SIDE MOULDING
REMOVAL
FRONT DOOR SIDE MOUNTING
1. Open the door and then loosen and remove
mounting screw (1) (1 Nos.) and mounting nut
(2) (1 Nos.).which are fitted on door shell.
2. Pry out the side moulding by plastic wedge
(Part No. 287158904002)
from out side and
remove it from the door.
FITMENT
For fitment of side mouldings properly locate the
clips and push against the door.
REAR DOOR SIDE MOUNTING
1. Open the door and then Loosen and remove
mounting screw (1) (1 Nos.) and mounting nut
(2) (2 Nos.).which are fitted on door shell.
2. Pry out the side moulding by plastic wedge
(Part No. 287158904002)
from out side and
remove it from the door.
NOTE
Before fitment check the condition of the side
moulding if found damaged replace with new one
at the time of assembly.
FITMENT
For fitment of side mouldings properly locate the
clips
and
push
against
the
door.
