ENGINE2.2LDICOR
l Assemble the upper cooling pipe lines, oil
separator assembly etc.
l Fit the cooling lines to oil cooler
l Fit the oil filter by rotating it to 3/4th turn after the
rubber seal makes contact with the oil cooler
bracket using special spanner.
Fig. 191
Fig. 192
l Remove the protective caps of injector's leak of
lines. Fit the injector's leak of lines. (Fig. 192)
