ENGINE2.2LDICOR
l
Fit the HP pipe between common rail & HP pump
(after removing the protective caps) (Fig. 181 &
182)
Fig. 179
Fig. 180
Fig. 181
l
Fit the EGR tube between EGR valve & Intake
elbow-Intake manifold (Fig. 179)
l
Fit the EGR pipe between EGR valve & exhaust
manifold (Fig. 180)
