877 / 1526
21
ENGINE2.2LDICOR
Fig. 34
Fig. 35
Fig. 36
l
Release the timing belt tension by loosening the
auto tensioner mounting bolt (Fig. 34)
l
Remove the timing cover-lower (Fig. 35)
l
Take out the timing belt. (Fig. 36)
|
|
