REAR AXLE
TABLE A
Old Pinion
New Pinion Marking (English) (Value in Inches)
Marking
(English)
-4
-3
-2
-1
0
+1
+2
+3
+4
+4 +0.008 +0.007 +0.006 +0.005 +0.004 +0.003 +0.002 +0.001 0
+3 +0.007 +0.006 +0.005 +0.004 +0.003 +0.002 +0.001
0
-0.001
+2 +0.006 +0.005 +0.004 +0.003 +0.002 +0.001
0
-0.001 -0.002
+1 +0.005 +0.004 +0.003 +0.002 +0.001
0
-0.001 -0.002 -0.003
0 +0.004 +0.003 +0.002 +0.001
0
-0.001 -0.002 -0.003 -0.004
-1 +0.003 +0.002 +0.001
0
-0.001 -0.002 -0.003 -0.004 -0.005
-2 +0.002 +0.001
0
-0.001 -0.002 -0.003 -0.004 -0.005 -0.006
-3 +0.001
0
-0.001 -0.002 -0.003 -0.004 -0.005 -0.006 -0.007
-4
0
-0.001 -0.002 -0.003 -0.004 -0.005 -0.006 -0.007 -0.008
TABLE B
Old Pinion
New Pinion Marking (Metric) (Value in mm)
Marking
(Metric)
-10
-8
-5
-3
0
+3
+5
+8
+10
+10 +.20
+.18
+.15
+.13
+.10
+.07
+.05
+.02
0
+8 +.18
+.16
+.13
+.11
+.08
+.05
+.03
0
-.02
+5 +.15
+.13
+.10
+.08
+.05
+.02
0
-.03
-.05
+3 +.13
+.11
+.08
+.06
+.03
0
–.02
-.05
-.07
0
+.10
+.08
+.05
+.03
0
-.03
-.05
-.08
-.10
-3
+.07
+.05
+.02
0
-.03
–.06
-.08
-.11
-.13
-5
+.05
+.03
0
–.02
-.05
–.08
–.10
-.13
-.15
-8
+.02
0
-.03
-.05
-.08
-.11
-.13
–.16 –.18
-10
0
-.02
–.05
-.07
–.10
-.13
-.15
–.18 –.20
Note:
Please observe the marking on the pinion. If ‘m’ is found etched on the face, refer table
B
. If not refer
table
A
.
