8
REAR AXLE
CONSTRUCTION :
Fig. 1a
SAFARI REAR AXLE (DANA - M44)
FOR ABS WITH - WITHOUT
LIMITED SLIP DIFFERENTIAL
WHEEL NUT BRAKE DRUM
WHEEL BOLT
SERRATED BRAKEBOLT
BRAKE ASSEMBLY
WITH AUTO
ADJUSTER
A LESHAFT
RETAINER PLALE
OIL SEAL
UNIT
BEARING
BEARING
RETAINER
ABS TONER
RING
WHEEL SPEED
SENSOR
NUT
LOCKNUT
OIL SEAL
THRUST WASHER
BEARING CONE
BEARING CUP
PINION NUT
WASHER
END
YOKE
BREATHER
VENT
COLLAPSIBLE
SPACER
BEARING CUP
BEARING CONE
SHIM PINION POSI-
TION
DIFF CASE (STD)
ROLL PEN
GEAR PAIR (RING GEAR/PINION)
RING GEAR
SCREW
PLUG
COVER SCREW
RATIO CAP
COVER
BEARING CAP SCREW
BEARING CAP
BEARING CAP
DIFF PIN
THRUST WASHER
PINION MATE
THRUST WASHER
SIDE GEAR
SIDE GEAR
PINION
MATE
THRUST
WASHER
PINION
MATE
SHIM DIFF PRELOAD
BEARING CONE
SIDE GEAR
THRUST WASHER
SIDEGEAR
DISC
SIDE GEAR
WASHER
PINION MATE
SIDE GEAR
PINION MATE
THRUST
WASHER
DIFF PIN
RING GEAR
SCREW
DIFF
CASE
(LSD)
PLATES
PIN ROLL
RETAINER
CLIP
