PROPELLER SHAFT

3

Fig. 3 : 4x2 Front propeller shaft

CONSTRUCTION

ITEM DESRIPTION

1 UNIVERSAL JOINT CROSS

2 TUBEYOKE

3 TUBE

4 TUBE SHAFT

5 SLINGER

6 BRACKET

7 BEARING

ITEM DESRIPTION

8 C B RUBBER

9 DUST SEAL

10 DUST SEAL RETAINER

11 'L' TYPE SPACER

12 SLIP YOKE ASSEMBLY

13 CENTREYOKE

14 SPRING

15 D C YOKE
