SAFARI

GEAR BOX G-76

Loosen and remove screws of detent cover.

Remove springs and balls. Ref Fig. 36

Fig. 36

Fig. 37

Fig. 38

Take out shifter shaft 3rd/4th along with inter lock pin.

Ref Fig. 37

Take out main shaft assembly along with the counter

shaft and shifter shafts from the gear box housing -

Rear half. Ref Fig. 38

(The main shaft assembly, counter shaft and shifter

shafts can be removed along with drive shaft).

Note: Ensure that engaging sleeve does not jump out

of engaging gear.

Take out inter lock balls.

Separate out counter shaft assembly and shifter shafts

from main shaft assembly.
