SAFARI

GEAR BOX G-76

Fig. 13

Fig. 15

Fig. 14

DISMANTLINGOF GEAR SHIFT LINKAGE:

DISMANTLINGOF GEAR BOX

(The gear box is removed from the vehicle)

Remove clutch release bearing and fork. Ref fig. 13.

Remove clutch housing by loosening nuts. Ref fig. 14.

Mount the gear box on drive shaft end face on work

stand (Pt. No. 2573 5890 37 01) fitted with mounting

Plate Pt. No. 2654 5890 2613. Drain the oil.

Remove breather. Ref fig. 15.
