SAFARI

GEAR BOX G-76

REMOVALOF GEAR BOX FROMVEHICLE:

Place the vehicle properly on pit or lift. Place chocks

on wheels.

Disconnect battery terminal cables, electrical

connections of starter motor and remove starter motor.

Drain the oil from the gear box by removing the drain

plug. Collect this oil in a container.

Remove the connection of the speedometer drive by

unscrewing it.

Remove the connection of the reverse indication switch.

The connectors should be properly kept to side.

Remove the earthing cable by loosening the bolt on

the clutch housing. The cable should be properly

clamped to one side so that it dose not get twist or

left hanging.

Fig. 01

Fig. 02

Fig. 03
