ENGINE2.2LDICOR
173
Sr.
Fault for
Pin
Fault
Service
MILLamp
Fault code
Symptoms
Tocheck
To rectify
No
the sensor
Description
Lamp
20
ATM PRES
Short circuit
P107/P0108
SENSOR
to -ve/+ve
Global Fault
P1107
Gradient fault
P109
Supply volatge
P0105
problem
21 GLOW PLUGS
Open Circuit
P1678
Maximum engine
1. Glow Plug box
Remove and connect again
speed - 4000 rpm .
connection
168
Short to Gnd
P1680 / P0380
CE comes @ IGN ON 2. Electrical
wiring
Terminal backout, wire open
after 10 sec
circuit & short circuit
179
Short to Gnd
P0380
3. ECU connection
Connect properly
Glow Plug driver
P0380
Maximum engine
4. Glow Plug box
Change glow plug box
fault
speed - 4000 rpm .
malfunctioning
22
LAMPS
GP lamp
208
Short to - ve
Glow plug symbol in
1. Electrical
wiring
Terminal backout, wire open
cluster keeps glowing
circuit & short circuit
WIF lamp
209
Short to - ve
Water In Fuel lamp ON
SERVICE lamp
245
Short to - ve
P1650
MIL lamp
240
Short to - ve
P0650
ECU isnotprotectedforshortofECUpowersupplytoECUGroundpins.Alsogroundpinsshortingto+vesupply.InsuchcasesECUwillgetdamaged.
These are only indicative details.For the correct details , theDelphi diagnosticmanualis to be given the preferance.
