ENGINE2.2LDICOR
164
1 CAMSENSOR
-
OpenCircuit/
P0340
Enginedoesnotstart,
1.CamSensorconnection
Removeandconnectagain
Looseconnector
CElampcomesONat
cranking only
137
Short circuit to
P0340/P1120/P0642/
Enginedoesnotstart
2. Electrical wiring
Terminal backout, wire open
-ve/+ ve
P1123/P0122/P0190
circuit & short circuit
138
Short circuit to
P0340/P0335
Enginedoesnotstart
3. Sensormalfunctioning /
Clean/Changesensor.
-ve/+ ve
Airgap
CorrectAirgap
114
Short circuit to
Enginestarts
4.EngineCam/Crank
Check timing and rectify
-ve/+ ve
Timing (belt slippage)
-
Camsignalfault
P0341
Enginedoesnotstart
5.TargetcamshaftFlag
Clean/Changecamshaft
/Notsyncronised
Invalidsignal
Dimension
target
with crank
2 CRANKSENSOR
-
OpenCircuit/
P0335
Enginedoesnotstart,
1.CrankSensorconnection Removeandconnectagain
Looseconnector
CElampcomesONat
crankingonly
181
Short circuit
-
2. Electrical wiring
Terminal backout, wire open
to -ve
circuit & short circuit
187
Short circuit
P0335/P1193/P1646 Enginedoesnotstart
3.Sensormalfunctioning
Clean/Changesensor
to -ve
188
Short circuit
-
4.AirGap
PutCopperwasher
to -ve
181
Short circuit
P1101/P0103/P0113 Enginedoesnotstart
5.EngineCamshaft/
Check timing and rectify
to +ve
/P0193
CrankShafttiming
187
Short circuit
P0335/P1101/P0103/
Enginedoesnotstart
6.FlywheelTeeth
Clean/Changewheel.
to +ve
P0113/P0193
Dimension /
Check flywheel reference
Flywheel reference
188
Short circuit
P0335/P1101/P0103/
Enginedoesnotstart
to +ve
P0113/P0194
-
CrankSignalfault-
P0371
Enginedoesnotstart
Edgestooclose
-
CrankSignalfault-
P0336
Enginedoesnotstart
LossofGap
-
CrankSignalfault-
P0372
Enginedoesnotstart
MissingTooth
3 KNOCKSENSOR
-
OpenCircuit/
P0325
Enginestarts,
1.Sensorconnection/
Removeandconnectagain
Looseconnector
CEcomesOnafter
Wrongknocksensor
20secofstarts,
assembly
Engine
143
Short circuit
Enginesrunsnoisy
2.GroundingofKnock
GroundProperly by tightening
to -ve
sensor /Torque to the
mounting bolt
bolt
Sr.
Fault for
Pin
Fault
Service
MILLamp
Fault code
Symptoms
Tocheck
To rectify
No
the sensor
Description
Lamp
