8.25.2 BCM FUNCTIONS:
The inputs and the outputs shall be understood as
hardwired, CAN, LIN, RF signals based on the
below mentioned color-coding.
Black: Hardwired signals
Blue: CAN message
Brown: LIN message
Green: RF signals
1. EXTERIOR LIGHTS
1.1 Turn Indicators and Hazard Lamps.
1.2 Turn Tip – Lane Changer.
1.3 Brake Lamps.
1.4 Head Lamp - Low Beam.
1.5 Head Lamp - High beam
1.6 Approach Lamps.
1.7 Position Lamps.
1.8 Front Fog Lamps
2. INTERIOR LIGHTS
2.1 Roof Lamp (With Dimming)
2.2 Illuminated Ignition Switch (Key Hole) –
Parallel to Roof Lamp
3. WIPER WASHER
3.1 Front wiper low speed/ high speed/
momentary
3.2 Front wiper Intermittent.
3.3 Front washer with drip wipe.
3.4 Rear Wiper Control.
3.5 Rear Wash Control
4. VEHICLE POWER MODE
4.1 Battery Saver Functionality
4.2 Accessory Delay Functionality.
4.3 Transport mode functionality
4.4 Vehicle Power Mode Management
4.5 Active Wake-up Capability
5. CENTRAL LOCKING & RKE
5.1 Central Locking and Unlocking
5.2 Drive Away Locking
5.3 Auto Relock.
5.4 Remote Locking / Unlocking
5.5 Crash Unlock (Auto door unlock on impact
sense)
6. USER CUSTOMIZATION SETTINGS
7. REAR DEFOGS CONTROL.
