1.2L REVOTRON ENGINE
18
Intake Manifold :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 ETC to Intake Manifold (HEX.Nut AM6) (4 Qty)
1.0
2 ETC to Intake Manifold (STUD CM6X45) (4 Qty)
1.0
3 Electronic Throttle Control
4 Gasket (For Electronic Throttle Control)
5 MAP Sensor
6 Hex FL Screw M6X10
1.0
7 Intake Manifold
8
Self-Locking Nut (Clinch Nut M8 X 1.25) (4 Qty)
•
2.0+0.3
9 M8X30 at bottom of intake manifold on block (1 Qty)
2.5
10 Grommet on intake manifold (Bottom)
11 Grommet on intake manifold for air filter (Top)
12 Gasket (Intake Manifold) (3 Nos)
13 Intake Manifold Stud
2.5
Note:-
•
This Symbol indicates critical tightening torque.
