DRIVETRAIN-TA65 Star
2
4.2. SPECIFICATIONS AND TIGHTENING TORQUES
4.2. A. CLUTCH
TECHNICAL SPECIFICATIONS:
TYPE
PETROL
DIESEL
Cover Assembly
Single disc dry friction
Diaphragm spring type
Single disc dry friction
Diaphragm spring type
Clutch type – Valeo
Disc Assembly
Non-asbestos LUK B8080
facings
Pre-damper XB(D) type
F810DS Valeo facings
Release bearing Assembly
Self-Centering Type
Self-Centering Type
CLUTCH DISC
1. Outer Diameter
200 mm
200 mm
2. Inside Diameter
134 mm
134 mm
3. Thickness of Clutch disc with
new lining under 3850 N load
7 ± 0.2 mm
7 ± 0.2 mm
4. Max. Permissible imbalance
of clutch disc
30 gm-cm
30 gm-cm
5. Cushioning of Clutch disc
0.65 to 0.9 mm
0.6 to 0.9 mm
6. Total Friction Area (Both
sides)
346 sq. cm
346 sq. cm
TIGHTENING TORQUES
Clutch Housing to Cylinder block
4.6 mkg.
4.6 mkg.
Clutch Pressure plate mounting
bolts
2.4 mkg.
2.4 mkg.
