216 / 1002
1.05L REVOTORQ ENGINE
5
SR
NO
TOOL
DESCRIPTION
TOOL
PART NO
APPLICATION
11
Camshaft Locking
Pin
5424 5890 06 01
12
Adaptor For Engine
Compression Testing
2868 5890 07 01
13
Drift (Valve Guide
Intake / Exhaust - Dia
5.2)
2868 5890 06 05
14
Spacer For Fitment
Of Valve Guide Along
With Drift
2868 5890 06 06
15
Mandrel For Aligning
Clutch Disc
2702 5890 25 01
