GENERAL
5
1.4 VEHICLE JACKING AND LIFTING POINTS:
Make sure you follow the manufacturer’s
instructions while lifting the car on two post lift.
• Always ensure vehicle balance in service
while applying two post lift to under body.
• Care should be taken that the two post lift arm
is not in contact with the bracket, brake or fuel
pipes etc.
• Before servicing, make sure to lock the lift
after the vehicle is lifted up.
• Following fig shows the front and the rear
jacking points by two post lift
JACKING POINTS
Front and Rear jacking point
USING THE FLOOR JACK:
• Use the jacks at the locations as shown in the
below.
• Do not apply the jack against any part which
may get deformed.
• If front end or rear end of the vehicle is to be
jacked ensure the wheels on ground and the
parking brake is applied.
Front jacking point
Rear jacking point
TOWING THE VEHICLE:
• For towing a car, the best way is to use a
wrecker. Alternatively use a rigid tow bar.
• Avoid using a flexible cable or rope as your
car may crash into the car towing your car
when it stops suddenly.
• Switch ‘ON’ the hazard warning signals of
both the cars to warn other road users.
• Where possible, keeps the engine idling so
that power steering assistance and brake
vacuum are available.
• Limit the speed to 20-30 Kmph.
• In case of brake failure, use the parking brake
to control the car.
