FRONT AXLE - 4
X
4
Cut boot clamp & discard.
Fig. 69
Cut boot and discard.
Fig. 70
Boot champs and boot are not to be reused.
Wipe away grease, to make the snap ring of inner
race visible.
Expand snap ring and remove shaft by tapping on
outer race by brass hammer.
Place the CV joints in vise
Note :
Use soft TeflonV-jaws, to prevent the damage
to splines.
Mount the ball assembly Pt. no. 2704 5890 3333 tool.
Fig. 71
Fig. 69
Fig. 70
Fig. 71
