GEAR BOX G-76
Push the bush with the help of drift,
Pt.No. 2654 5890
35 11. Ref Fig. 83
Note :
The spacer has to be heated to 100°C to 120°C
before assembly.
Fig. 83
Slide 3
rd
gear sub-assembly along with the needle roller
cage and 3
rd
/ 4
th
engaging gear over main shaft keeping
engaging gear upwards. Ref fig. 84
Fig. 84
Slide spacer ring over main shaft.
Ref Fig. 85
Fig. 85
