ARIA

ENGINE

E. DRAINING WATER FROM PREFILTER CUM

SEDIMENTOR

1. Stop the engine allow the pressure to stabilize.

2. Disconnect the sensor pigtail and also disconnect

one of the fuel lines either inlet or outlet.

3. Keep a suitable container to collect the drained

water

4. Rotate the sedimentor sensor in an anti-clockwise

direction for about 2 turns and allow approximate-

ly 120cc of diesel to drain and then tighten the

sensor.

5. Connect the fuel line and pigtail that was discon-

nected in step 2.

6. Using hand priming pump refill the fuel line.

NOTE

For priming procedure refer fuel system in this group.

F. PREFILTER CUM SEDIMENTOR REPLACE-

MENT

1. Remove Front LH wheel assy & inner wheel arch

cover (

For procedures refer body section

2. Disconnect the sensor pigtail.

3. Keep a suitable container below the sensor to

collect the diesel that will drain

4. Remove the sensor by unscrewing it in anti-

clockwise direction.
