ARIA

GENERAL

1.3.3 COMPONENT LOCATIONS

1.3.3.1 JACK, TOOL BAG AND WHEEL SPAN-

NER LOCATION

The jack is kept in the rear luggage space of your

vehicle. Open the tail gate and lift the cover of the

storage box to access the scissor jack.

1.3.3.2 WARNING TRIANGLE

LOCATION

Warning triangle is located below third row seat

placed on vertical face & held with Velcro straps.

1.3.3.3 FRONT TOW HOOK

LOCATION

Front tow hook provision can be seen at the left side

of front bumper after removal of cap. The cap can be

removed by pulling it outwards.

1.3.3.4 REAR TOW HOOK

LOCATION

Rear tow hook provision can be seen at the centre

on the rear bumper after removal of cover. This cov-

er can be removed by pulling it outwards. Tow hook

can be fitted on either of the holes provided at the

rear.
