ENGINE2.2LDICOR
13. Water in fuel senso
r (Fig. 235)
It Measures water percentage in fuel and gives
indication on the instrument cluster. The water
collected to be drained when the indicator glows
in Instrument panel (Refer sedimenter section).
Fig.235
13. ClutchSwitch
(Fig. 236)
It provides information to ECU before the gear
change, which helps in faster gear change
detection. Based on this input the ECUmaintains
optimum fuel supply.
13. Brake Switch
(Fig. 237)
It provides information to ECU about the brake
application and ECU maintains the optimum fuel
supply.
Fig. 236
Fig. 237
