ENGINE
46
9. Disconnect the coolant vent tube from the coolant
outlet pipe and remove it from the clips.
10.Disconnect the vacuum hose from the vacuum
solenoid valve
(1
) and remove the vacuum sole-
noid valve
(1
) from the bracket.
11.Remove the coolant hoses from the EGR module
assembly.
12.Loosen the bolts and remove the EGR outlet pipe
from EGR module assembly.
13.Loosen the bolts and remove the EGR module
assembly.
(For procedure refer EGR removal re-
moval in Exhaust section).
