FRONT SUSPENSION
21
FRONT
SUSPENSION
B. UPPER WISHBONE BUSH
1. Remove the Upper Wishbone suspension bush
using special tool assembly
(Part No.
2870
5890 01 12)
as shown in below arrangement.
2. Mount the upper wishbone assembly on to the
fixture
(1)
and lock the same by tightening the
socket head screws
(4 Nos.)
of the upper plate
and tighten the grab screw
(3 Nos.)
of the
support to lock the bush housing for any
movement while pressing out the bush.
3. Place the drift
(2)
between the Upper
Wishbones as shown in figure.
4. Place the base
between the drift and upper
wishbone and insert the Extension
(3)
through
the rubber bush and lock it with the base.
5. Press the Extension with the hydraulic press
and take out the Wishbone bush.
NOTE
Follow the same procedure for bush removal at
other end.
