SAFARI STORME MY14

BODY

REMOVAL

1. Before starting to remove first lower the window

glass.

2. Remove the door trim.

(For procedure refer

door trim removal procedure in this section.)

3. Loosen and remove mounting screw from body

shell and take out outer belt of door window.

Remove the glass mounting screws

5. Remove the glass mtg. clip and take out the

glass from the window

6. Remove electrical connection of window

winding motor.

7. Remove one screw and two nuts of winder

(Motor)

8. Remove mounting nuts of winding mechanism

which were loosened earlier and take out the

winding mechanism from door shell.

FITMENT

For fitment follow the reverse procedure of

removal.

NOTE

During fitment of front door glass first fit the

window winding motor.
