804 / 1428
834
HVAC
SYSTEM LAYOUTS
A/C SYSTEM LAYOUT
1
2
3
5
4
7
6
1 A/C compressor
2 A/C lines/pipes
3 A/C control panel
4 A/C unit
5 Blower assembly
6 Condenser assembly
7 Pressure switch
SCHEMATIC OF AC SYSTEM
|
|
