DRIVETRAIN
391
DRIVETRAIN
7. Insert the spacer and place the first and second
gear spring (black) to rest on the spacer.
8. Insert the reverse gear spring (green) to rest on
the circlip.
9. Place the cup and press and hold it down.
10. Holding the cap down place the top cover plate
and tighten the four M6 bolts to a torque of 0.85
~ 1.25 kgm.
11. Place the spacer and fit the circlip on the slot.
12. Place the spring in the barrel.
