ENGINE 273 MPFI
ENGINE
•
Pull out the filter housing from the remaining two
press fitted mountings.
Refitment of Air filter Housing:
•
Follow the above procedure for removal of air filter
housing in reverse order.
INTAKE MANIFOLD
Removal of intake manifold from vehicle:
•
Remove rear seat completely from vehicle. (Refer
Removal procedure of Rear Seat fromBody group)
•
Take out engine access cover with the help of screw
driver.
NOTE
Six notch locks are provided on insulation engine
cover. Insert the screw driver at any notch position
to facilitate easy removal of cover from body.
