ENGINE 273 MPFI
SYSTEM COMPONENTS
Fuel Filler Cap
Location:
Fuel Filler Cap is mounted inside the front hood on
the right side of spare wheel.
Function:
A ratchet tightening device on the threaded fuel filler
cap reduces the chances of over tightening and incor-
rect installation, which would prevent sealing fuel
vapours. After the ‘O’ ring on fuel filler cap and the fuel
filler neck flange contacts, the ratchet produces a loud
clicking sound, indicating the seal has been set.
Remove the cap while fuel filling.
Fuel Tank
Location:
The fuel tank is located below the co-driver seat under
body as shown in fig. The fuel module is mounted on
the upper part of fuel tank.
Function:
Fuel storage.
