ENGINE 273 MPFI
189
ENGINE
•
Fit rear timing cover & tighten all hexagonal
mounting bolts to the specified torque.
•
Fit sensor wheel on crank shaft.
•
Insert the key between crank shaft & sensor wheel.
Note:
While inserting sensor wheel on crankshaft,
ensure that step on sensor should remain on front
side.
•
Fit timing gear on crank shaft.
•
Fit the timing belt tensioner & slightly tighten the
mounting screw.
•
Fit the cam shaft gear on cam shaft & slightly
tighten the mounting bolt.
