ELECTRICAL
2
Loosen the positive terminal of battery and
take out the battery along with fuse box.
Place / secure both the terminals (Negative
and Positive) carefully.
Now lift the battery and remove from battery
tray.
REFITTMENT
For fitment procedure, follow the reverse procedure
of “Removal”.
6. STARTER MOTOR
A. EXPLODED VIEW
B. ON VEHICLE REMOVAL AND REFITTMENT
OF STARTER MOTOR
REMOVAL
Disconnect battery negative terminal.
Disconnect Starter motor positive terminal.
6
